Mito-MI-1301003

Square Drive : 1/2”
Standard Bolt Size : 5/8”(M16)
Free Speed : 8000 RPM
MAX Torque : 400Ft/lb(542Nm)
Overall Length : 6.1/8”(155mm)
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Avg. Air Con- sumption : 4cfm(113L/min)
Net Weight : 5.94Lbs(2.7Kgs)
Sound DBA Pre : 90DB
Vib. : 1.3M/S2

Mito-MI-1301004

Square Drive : 1/2”
Standard Bolt Size : 5/8”(M16)
Free Speed : 8000 RPM
MAX Torque : 400Ft/lb(542Nm)
Overall Length : 8.1/8”(206mm)
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Avg. Air Con- sumption : 4cfm(113L/min)
Net Weight : 6.2Lbs(2.82Kgs)
Sound DBA Pre : 90DB
Vib. : 0.9M/S2

Mito-MI-1301006

Square Drive : 3/4”
Standard Bolt Size : 1”(M25)
Free Speed : 6500 RPM
MAX Torque : 750Ft/lb(1016Nm)
Overall Length : 9.19/64”(236mm)
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Avg. Air Con- sumption : 7cfm(198L/min)
Net Weight : 10Lbs(4.55Kgs)
Sound DBA Pre : 87DB
Vib. : 0.7M/S2

Mito-MI-1301014

Square Drive : 3/4”
MAX Torque : 260(353Nm)
Free Speed : 7000 RPM
Net Weight : 2 KGS
Avg. Air Cons. : 4.5 CFM
Air Pressure : 90 PSI
Air Inlet : 1/4”
Air Hose : 3/8” ID

Mito-MI-1302010

Square Drive : 1/2”
Working Range Torque : 50-300 ft / lbs
Max. Torque : 350 ft / lbs
Free Speed : 7000 RPM
Net Weight : 1.47 KGS
Avg. Air Cons. : 4.5 CFM
Air Pressure : 90 PSI
Air Inlet : 1/4”
Air Hose : 3/8” ID

Mito-MI-1302001

Air Impact Wrench 10 pcs.
Impact Sockets 8 10 12 13 14 17 19 21 24
27 mm Mini Oiler
125 mm Extension Bar
Nipple PM20
Oil Pot
4mm Hex key

Mito-MI-1202003

Bolt Capacity : 4 - 5 mm
Speed : 9000 RPM
Air Pressure : 6 kg/cm2
Torque : 14.5Nm
Overall Length : 158 mm
Net Weight : 0.70 kg
AV-Air Consumption : 0.22 M3/Min

Mito-MI-1202004

Bolt Capacity : 4 - 5 mm
Speed : 9000 RPM
Air Pressure : 6 kg/cm2
Torque : 18Nm
Overall Length : 165 mm
Net Weight : 0.72 kg
AV-Air Consumption : 0.22 M3/Min

Mito-MI-1202005

Bolt Capacity : 5 - 6 mm
Speed : 8500 RPM
Air Pressure : 6 kg/cm2
Torque : 23.5Nm
Overall Length : 200.5 mm
Net Weight : 1.01 kg
AV-Air Consumption : 0.25 M3/Min

Mito-MI-1202006

Bolt Capacity : 6 mm
Speed : 8500 RPM
Air Pressure : 6 kg/cm2
Torque : 28.0Nm
Overall Length : 202 mm
Net Weight : 1.03 kg
AV-Air Consumption : 0.25 M3/Min

Mito-MI-1203002

Bolt Capacity : 5 - 6 mm
Speed : 10000 RPM
Air Pressure : 6 kg/cm2
Torque : 28.5Nm
Overall Length : 180 mm
Net Weight : 1.22 kg
AV-Air Consumption : 0.25 M3/Min

Mito-MI-1202002

Capacity Screw Size : 1/4”(M6)
Free Speed : 8500 RPM
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Avg. Air Consumption : 10.6cfm(300L/min)
Torque : 150Nm
Overall Length : 7.61/64"(202mm)

Mito-MI-1401002

Square Drive : 1/2"
Free Speed : 150 RPM
MAX. Torque : 45Ft/lb(6.22Kg/m)
Overall Length : 267mm
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Air Pressure : 90psi(6.3Kgcm2)
Avg. Air Consumption : 6cfm(168L/min)
Net Weight : 1.17 Kg
Sound DBA Pre : 91Db
Vibration : 1.0M/S2

Mito-MI-1401003

Square Drive : 1/2"
Free Speed : 170 RPM
MAX. Torque : 50Ft/lb(6.90Kg/m)
Overall Length : 267mm
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Air Pressure : 90psi(6.3Kgcm2)
Avg. Air Consumption : 6cfm(168L/min)
Net Weight : 1.17Kg
Sound DBA Pre : 93Db
Vibration : 1.1M/S2

Mito-MI-1401010

Square Drive : 3/8"
Free Speed : 230 RPM
MAX. Torque : 30 Ft/lb(4.15Kg/m)
Overall Length : 165mm
Air Inlet PT : 1/4”
Air Hose I.D. : 1/4”
Air Pressure : 90 psi(6.3Kgcm2)
Avg. Air Consumption : 3cfm(85L/min)
Net Weight : 0.50Kg
Sound DBA Pre : 93Db
Vibration : 1.2M/S2

Mito-MI-1501002

Sprindle Thread : 3/8"-24 "
Chuck Size : 3/8” (10mm)
Free Speed : 1800RPM
Overall Length : 6.5/8"(170mm)
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Recommended Air Pressure : 90 psi/6.3 bar
Avg. Air Consumption : 6cfm(168L/min)
Net Weight : 2.42Lbs(1.1 Kgs)
Sound DBA Pre. : 98.8Db
Vibration : 2.5M/S2

Mito-MI-1501003

Sprindle Thread : 3/8"-24"
Chuck Size : 3/8”(10mm)
Free Speed : 2200RPM
Overall Length : 6.3/8"(162mm)
Air Inlet PT : 1/4”
Air Hose I.D. : 3/8”
Recommended Air Pressure : 90 psi/6.3 bar
Avg. Air Consumption : 6cfm(168L/min)
Net Weight : 2.42Lbs(1.1Kgs)
Sound DBA Pre. : 98.8Db
Vibration : 2.5M/S2

Mito-MI-2901001

ขนาด : 3mm
Air Pressure : 5-6 KG/CM2
Hose : 148cm
Regular Speed : 60,000RPM
Net Weight : 0.26Kgs

Mito-MI-2901002

ขนาด : 3 & 6mm
Air Pressure : 5-6 KG/CM2
Hose : 148cm
Regular Speed : 30,000RPM
Net Weight : 0.40Kgs

Square Drive : 3/8”
Free Speed : 350RPM
MAX. Torque : 20Ft/lb
Over- all Length : 130mm
Air Inlet : 1/4”-19PT
Air Hose I.D. : 1/4”
Air Pressure : 90Psi(6.2Bar)
Net Weight : 0.45Kgs
Sound DBA Pre : 99Db
Wb : 3.6m/s2

Mito-MI-2902005

ขนาด : 6mm
Overall Length : 5.28”(134mm)
Air Pressure : 90Psi(6.2Bar)
Air Inlet : 1/4”-19PT
Regular Spec : 26,000 RPM
Net Weight : 0.36Kgs
Sound Level : 86DBA

Mito-MI-2902005

ขนาด : 6mm
Overall Length : 5.51”(140mm)
Air Pressure : 90Psi(6.2Bar)
Air Inlet : 1/4”-19PT
Regular Spec : 20,000 RPM
Net Weight : 0.50Kgs
Sound Level : 93DBA

Mito-MI-1601004

Size Of Pad : 4”
Speed : 11000 RPM
Spindle Thread : M10x1.5
Air Consumption : 6 cfm
Air Inlet : 1/4"

Mito-MI-7001001

Capacity :
For setting blind rivets
up to 4.8mm (3/16”)

Nosepieces:
4.8 mm (3/16”)
4.0 mm (5/32”)
3.2 mm (1/8”)
2.4 mm (3/32”)

Net Wt : 1.5 kgs
Air inlet : 1/4”
Air Cons : 0.03cfm (0.85L/min) / cycle
Air Pressure : 6kg/cm2 (90 Psi)

Mito-MI-1602007

Size Of Pad : 7”
Speed : 2500 RPM
Spindle Thread : 5/8”
Air Consumption : 15.3 cfm
Air Inlet : 1/4"

Mito-MI-2001001

SPECIFICATIONS
๏ Boosts Grease Pressure up to
69,000 kpa / 10,000 P.S.I. / 690 Bar
๏ Rigid Outlet
๏ Grease Inlet 1/4” NPT (F) Note 1/8” NPT
Adaptor also supplied
๏ 360o ZSB Swivel included
๏ Optional Extra with Grease Pump

Mito-MI-2001002

Mito-MI-6401001
